Frosted UI Kit
A modern, highly-customizable Flutter UI kit inspired by Apple's Liquid Glass aesthetic and Telegram's modern Android redesign.
❄️ Frosted UI Kit Catalog & API Indexing
For supported imports, compatibility aliases, and deprecation policy, see API Stability and Deprecation. For the shared visual surface rules, see Visual Consistency.
Welcome to the frosted_ui_kit Widget Catalog and Technical API Index. This document provides a complete visual reference, parameter guide, and code snippets for all components in the library.
📊 API & Widget Catalog Index
| Component | File / Module | Primary Class | Mixin Shortcut | Description |
|---|---|---|---|---|
| Input Fields | inputs.dart |
AppTextField |
emailField, passwordField, nameField, textField |
Pre-configured glassmorphic inputs with auto-obscure toggle, icons, and validation. |
| Glass Cards | cards.dart |
BlurredCard |
blurredCard (bluredCard) |
Translucent card container with backdrop blur filter (sigmaX: 10, sigmaY: 10). |
| Action Buttons | buttons.dart |
AppButton, CircleButton, AppFloatingActionButton |
appButton, circleButton, backButton, appFab |
Multi-styled buttons (glass, colored, outlined, text) and floating action buttons. |
| Sliding Tabs | tabs.dart |
AppSlidingTabs |
appSlidingTabs |
Telegram-style animated sliding segmented control with RTL support. |
| Bottom Sheets | bottom_sheet.dart |
AppBottomSheet |
showAppBottomSheet |
Modal bottom sheet with backdrop blur filter and drag indicator. |
| Dialogs | dialogs.dart |
AppDialog |
showAppWarningDialog, showAppErrorDialog, showAppInputDialog |
Pop-up glassmorphic dialogs for warnings, errors, and input prompts. |
| List Tiles | list_tile.dart |
FrostedListSection |
N/A | Grouped, glassmorphic settings-style lists with integrated dividers. |
| App Bars | app_bar.dart |
FrostedAppBar |
N/A | Modern, glassmorphic primary application bar with auto-fitting title. |
| Navigation Bars | navigation_bar.dart |
FrostedNavigationButtomBar, FrostedNavbarController |
N/A | Glassmorphic bottom navigation bar with animated tab selection. |
| Screen Layout | base_widget.dart |
BaseWidget |
Scaffold Wrapper | Screen wrapper providing integrated FrostedAppBar and FrostedNavigationButtomBar. |
| Auth Feature | features/auth/ |
AuthScreen, AuthController |
Complete Flow | Pure UI authentication screens (login, register, reset, verify). |
🧩 Widget Catalog & Detailed API Guide
1. 📝 Input Fields (AppTextField & Inputs)
Modern glassmorphic text input fields supporting pre-configured presets, automatic obscure text toggles for passwords, custom error feedback, and label support.
Supported Preset Variants (AppTextFieldType):
AppTextFieldType.email: Auto-configured with email keyboard, email icon, and validation.AppTextFieldType.password: Auto-configured with obscure text mask and interactive eye toggle button.AppTextFieldType.name: Auto-configured with word capitalization and person icon.AppTextFieldType.phone: Auto-configured with numeric phone keypad.AppTextFieldType.number: Auto-configured with numeric keypad.AppTextFieldType.multiline: Text area supporting multiline input.AppTextFieldType.text: Standard generic text field.
API & Key Parameters:
| Parameter | Type | Default | Description |
|---|---|---|---|
type |
AppTextFieldType |
text |
Field preset variant controlling defaults. |
label |
String? |
null |
Label text rendered above input box. |
placeholder |
String? |
null |
Hint text displayed when field is empty. |
controller |
TextEditingController? |
null |
Controller for managing text state. |
obscureText |
bool? |
Auto for password | Whether to mask text input. |
prefix |
Widget? |
Auto based on type | Leading icon or widget. |
suffix |
Widget? |
Eye icon for password | Trailing icon or widget. |
validator |
FormFieldValidator<String>? |
null |
Validation function for Form state. |
Code Usage Examples:
Email & Password Shortcuts via Mixin:
class LoginSampleWidget extends StatelessWidget with Inputs {
final _emailController = TextEditingController();
final _passwordController = TextEditingController();
@override
Widget build(BuildContext context) {
return Column(
children: [
emailField(
context: context,
controller: _emailController,
validator: (val) => val == null || val.isEmpty ? 'Required' : null,
),
const SizedBox(height: 14),
passwordField(
context: context,
controller: _passwordController,
),
],
);
}
}
2. 🧊 Glass Cards (BlurredCard & Cards)
Translucent glassmorphic container leveraging Flutter's BackdropFilter and ClipRRect to create realistic glass depth.
Smart Platform Optimization: BlurredCard automatically adapts to the platform for maximum performance:
- iOS: Uses the highly optimized BackdropFilter (via Impeller) with a smooth sigmaX/Y: 5.0.
- Android: Automatically falls back to Alpha Transparency (disableBlur = true) mimicking Telegram's approach for fluid performance on all devices. You can override this behavior by explicitly setting the disableBlur parameter.
API & Key Parameters:
| Parameter | Type | Default | Description |
|---|---|---|---|
child |
Widget |
Required | Child content inside the glass card. |
borderRadius |
BorderRadiusGeometry? |
BorderRadius.circular(radius) |
Custom border radius geometry. |
radius |
double? |
50 |
Circular corner radius when borderRadius is omitted. |
height |
double? |
null |
Explicit height for the container. |
width |
double? |
null |
Explicit width for the container. |
padding |
EdgeInsetsGeometry? |
null |
Inner padding surrounding child. |
margin |
EdgeInsetsGeometry? |
null |
Outer margin around card box. |
border |
BoxBorder? |
AppThemes.border |
Translucent border stroke decoration. |
sigmaX |
double |
5.0 |
Horizontal backdrop blur intensity. |
sigmaY |
double |
5.0 |
Vertical backdrop blur intensity. |
clipBehavior |
Clip |
Clip.hardEdge |
Content clipping behavior (optimized for speed). |
disableBlur |
bool? |
null (Auto) |
If true, disables the heavy blur filter and relies on alpha transparency. Defaults to true on Android and false on iOS. |
Code Usage Example:
class CardSampleWidget extends StatelessWidget with Cards {
@override
Widget build(BuildContext context) {
return blurredCard(
context: context,
padding: const EdgeInsets.all(16),
child: const Text('Frosted Glass Container'),
);
}
}
3. 🔘 Action Buttons (AppButton, CircleButton, AppFloatingActionButton & Buttons)
For a concise entry point use FrostedButton.primary(label:, onPressed:),
FrostedButton.secondary(label:, onPressed:), and
FrostedIconButton(icon:, tooltip:, onPressed:). Constructors are const and
need no BuildContext argument or mixin. Primary uses filled styling; secondary
uses outlined styling. Null callbacks disable the button. isLoading blocks
activation and displays progress; it does not automatically start a Future.
Provide localized labels/tooltips from the host application. Optional icon,
width, foreground/background colors and borderRadius allow common overrides.
Icon actions support selection and an optional appearance override.
The short API delegates to the existing widgets, so theme, keyboard interaction
and performance controls use the same implementation. AppButton,
CircleButton and their helpers remain supported without new deprecations.
Advanced blur/border/shadow customization remains on those existing APIs.
Buttons Catalog demonstrates the short API alongside the original controls.
Circular buttons expose selected/enabled semantics and an accessible tap action.
Their minimum layout target is 48 logical pixels. Disabled buttons do not
animate on press, and reduced-motion settings suppress press scaling. Back
helpers follow Directionality. Regression tests exercise keyboard activation,
RTL, tooltips and disabled state. Light/dark geometry baselines are stored in
test/goldens; Flutter's test font is used, so device typography still needs
visual review. Run flutter test to compare baselines and review image changes
before intentionally regenerating them with --update-goldens.
A comprehensive set of action buttons supporting 5 visual style variants (AppButtonStyle). It also includes AppFloatingActionButton which acts as a versatile FAB (icon only, text only, or extended icon + text).
Button meaning is independent from appearance. Use
FrostedActionRole.primary, secondary, or destructive on AppButton, or
the matching FrostedButton constructor. Both examples retain destructive
error colors:
FrostedButton.destructive(label: 'Delete', onPressed: deleteItem)
FrostedButton.destructive(
label: 'Delete',
style: AppButtonStyle.glass,
onPressed: deleteItem,
)
Resolution order is: local color and border overrides, then the corresponding
action colors in FrostedThemeData, then Material ColorScheme. Disabled
content/surfaces use onSurface; focus, hover, and pressed overlays use the
resolved role accent. Roles are also supported by icon buttons and FABs.
Existing buttons default to the primary role.
For a normal Future-based action, FrostedAsyncButton owns the state cycle and
does not require a controller:
FrostedAsyncButton(
title: 'Save changes',
icon: Icons.save_outlined,
onPressed: () async => repository.save(),
onSuccess: showSavedMessage,
onError: (error, stackTrace) => logger.record(error, stackTrace),
)
Activation is blocked synchronously while an operation is active. Success and
error feedback reset after feedbackDuration (1.2 seconds by default), or can
remain visible with null. Late results after unmount are consumed without UI
callbacks or state updates. Errors are delivered to onError; no Dialog or
SnackBar is opened automatically. FrostLoadingButtonController remains the
advanced API for manually controlled workflows.
Supported Style Variants (AppButtonStyle):
AppButtonStyle.glass: Translucent glassmorphic button with backdrop blur.AppButtonStyle.colored: Solid primary accent filled button.AppButtonStyle.outlined: Transparent button with primary border outline.AppButtonStyle.text: Subtle text-only button without border or card fill.AppButtonStyle.waterDrop: Lightweight liquid-highlight style for regular buttons and extended FABs.
FrostLoadingButton keeps its width during loading by default, uses a compact
24px indicator, and exposes configurable loadingLabel, successLabel, and
errorLabel semantics. Set collapseOnLoading: true to opt into the older
compact spinner layout.
The owner disposes its controller after removing the button. Listeners detach
when the controller changes or the button unmounts. Call start() synchronously
inside onPressed: live state checks block repeat taps before a rebuild.
Non-idle states reject taps while preserving feedback colors. The button does
not cancel application Futures; check mounted and invalidate stale requests
on Reset, as demonstrated in Loading Button Catalog. The loading-dialog catalog
is a dismissible preview with no delayed pop of an underlying route.
CircleButton now defaults to CircleButtonStyle.waterDrop and also supports
the explicit glass and solid styles. The water-drop surface uses a small,
performance-aware backdrop blur with a restrained highlight and rim. The old glass behavior remains
available by setting style: CircleButtonStyle.glass.
It uses lightweight gradients and highlights instead of a separate backdrop
blur, making small icon buttons look like liquid droplets with lower GPU cost.
The existing glass style remains the default.
circleButton(
context: context,
icon: Icons.settings,
style: CircleButtonStyle.waterDrop,
selected: true,
selectedColor: Colors.deepPurple,
selectedIconColor: Colors.white,
tooltip: 'Settings',
semanticLabel: 'Settings',
onPressed: openSettings,
)
API & Key Parameters:
| Parameter | Type | Default | Description |
|---|---|---|---|
title |
String? |
null |
Button label text string. |
icon |
IconData? |
null |
Icon displayed beside title label. |
style |
AppButtonStyle |
glass |
Visual style variant choice. |
role |
FrostedActionRole |
primary |
Semantic action role and color family. |
isLoading |
bool |
false |
Displays progress indicator when true. |
isDisabled |
bool |
false |
Disables touch interactions and dims colors. |
onPressed |
VoidCallback? |
null |
Tap callback handler. |
height |
double? |
48 |
Fixed button height. |
Code Usage Examples:
class ButtonSampleWidget extends StatelessWidget with Buttons {
@override
Widget build(BuildContext context) {
return Column(
children: [
// Glass Button
appButton(
context: context,
title: 'Glass Action',
style: AppButtonStyle.glass,
onPressed: () {},
),
const SizedBox(height: 10),
// Colored Button with Loading
appButton(
context: context,
title: 'Submit',
style: AppButtonStyle.colored,
isLoading: false,
onPressed: () {},
),
const SizedBox(height: 10),
// Navigation Back Button
Row(
children: [
backButton(context),
const SizedBox(width: 8),
closeButton(context),
],
),
const SizedBox(height: 10),
// Extended Floating Action Button
appFab(
context: context,
icon: Icons.add,
title: 'Create',
onPressed: () {},
),
],
);
}
}
3.1 🔄 Animated Loading Buttons (FrostLoadingButton)
A dynamic button wrapper built on AppButton that handles transitions between multiple states (idle, loading, success, error) using Lottie animations.
Available States (FrostLoadingButtonState):
idle: Displays the normal text and icon.loading: Shrinks (or maintains width) to show anAppLoadingIndicatorbuilt with Lottie.success: Shows a success icon with customizable success color.error: Shows an error icon with customizable error color.
Code Usage Example:
class LoadingButtonSample extends StatelessWidget {
final FrostLoadingButtonController controller = FrostLoadingButtonController();
@override
Widget build(BuildContext context) {
return FrostLoadingButton(
controller: controller,
title: 'Submit Data',
icon: Icons.upload,
onPressed: () async {
controller.start(); // Switch to loading
await Future.delayed(const Duration(seconds: 2));
controller.success(); // Switch to success
},
);
}
}
4. 🗂️ Sliding Segmented Tabs (AppSlidingTabs & Tabs)
Telegram-inspired sliding tab selector with an animated pill indicator that smoothly slides between tab options. Fully RTL-aware.
API & Key Parameters:
| Parameter | Type | Default | Description |
|---|---|---|---|
tabs |
List<String> |
Required | List of tab label strings. |
selectedIndex |
int |
Required | Currently active tab index. |
onTabChanged |
ValueChanged<int> |
Required | Callback triggered when a tab is tapped. |
height |
double |
46 |
Total height of tabs container. |
activeTextStyle |
TextStyle? |
Bold OnPrimary | Custom style for selected tab text. |
inactiveTextStyle |
TextStyle? |
OnSurfaceVariant | Custom style for inactive tab text. |
Code Usage Example:
class TabSampleWidget extends StatefulWidget with Tabs {
@override
State<TabSampleWidget> createState() => _TabSampleWidgetState();
}
class _TabSampleWidgetState extends State<TabSampleWidget> {
int _tabIndex = 0;
@override
Widget build(BuildContext context) {
return widget.appSlidingTabs(
context: context,
tabs: const ['Tab One', 'Tab Two', 'Tab Three'],
selectedIndex: _tabIndex,
onTabChanged: (index) => setState(() => _tabIndex = index),
);
}
}
5. 📑 Glassmorphic Bottom Sheets (AppBottomSheet & BottomSheets)
Translucent backdrop filter bottom sheet modal with drag handle indicator and automatic keyboard inset padding (viewInsets).
API & Key Parameters:
| Parameter | Type | Default | Description |
|---|---|---|---|
context |
BuildContext |
Required | Build context for navigator. |
child |
Widget |
Required | Sheet content widget. |
title |
String? |
null |
Optional header title string with close button. |
header |
Widget? |
null |
Replaces the default title header. |
actions |
Widget? |
null |
Footer pinned when space allows and scrollable on compact layouts. |
maxHeightFactor |
double |
0.92 |
Maximum fraction of usable keyboard-adjusted height. |
isScrollControlled |
bool |
true |
Allows sheet to resize with keyboard. |
Code Usage Example:
class SheetSampleWidget extends StatelessWidget with BottomSheets {
void _openSheet(BuildContext context) {
showAppBottomSheet(
context: context,
title: 'Modal Settings',
child: const Padding(
padding: EdgeInsets.all(16),
child: Text('BottomSheet Content Here'),
),
);
}
@override
Widget build(BuildContext context) {
return FrostedButton.primary(
label: 'Open Sheet',
onPressed: () => _openSheet(context),
);
}
}
6. 💬 Glassmorphic Dialogs (AppDialog & Dialogs)
Input dialogs submit through the same validation path from the confirmation
button and keyboard Done action. Invalid input keeps the dialog open. Cancel
returns null. AppDialog.actions provides an optional footer: on sufficient
vertical space only the body scrolls, while very short viewports scroll the
body and footer together. Keyboard insets are handled by Flutter's Dialog;
callers should not add the keyboard height to insetPadding again.
The dialog regression suite covers a short viewport above the keyboard, RTL with 2x text scaling, portrait/landscape viewport changes, and keyboard insets appearing/disappearing. Input tests verify invalid Done submission, valid Done and button submission, Cancel, and system back results. These are widget simulations; physical-device keyboard behavior still benefits from manual checks. The Input Dialog catalog includes a longer description for trying these scenarios interactively.
Dialogs and bottom sheets share FrostedAdaptiveSurfaceLayout. Headers and
actions remain visible on regular viewports, while short or keyboard-reduced
layouts use one scroll view. FrostedAdaptiveActions stacks at narrow widths
or accessibility text scale. Warning confirmations use
FrostedActionRole.destructive when isDestructive is true. See
FROSTED_ADAPTIVE_MODALS.md for compatibility and low-end-device behavior.
See FROSTED_PERFORMANCE.md for the shared rendering policy, presets, and
profile measurement protocol.
Glassmorphic popup dialogs designed to alert the user, ask for confirmation, or prompt for text input.
Available Mixin Methods:
showAppWarningDialog: Shows a warning dialog returning a boolean.showAppErrorDialog: Shows an error dialog with an OK button.showAppInputDialog: Shows an input dialog returning the submitted string, with support for validation.
Shared API & Key Parameters:
| Parameter | Type | Default | Description |
|---|---|---|---|
context |
BuildContext |
Required | Build context for navigator. |
title |
String? |
null |
Optional header title string. |
description |
String? |
null |
Optional description or body text. |
icon |
IconData? |
Varies | Optional top icon. Set to null to hide. |
iconColor |
Color? |
error |
Theme color applied to the icon and its background. |
confirmText |
String? |
localized | Optional positive/submit label override. |
cancelText |
String? |
localized | Optional negative label override. |
validator |
FormFieldValidator<String>? |
null |
Validation logic for showAppInputDialog. |
titleColor |
Color? |
null |
Custom color for the title text. |
descriptionColor |
Color? |
null |
Custom color for the description text. |
confirmButtonColor |
Color? |
null |
Custom background color for the confirm button. |
confirmTextColor |
Color? |
null |
Custom text color for the confirm button. |
cancelButtonColor |
Color? |
null |
Custom background color for the cancel button. |
cancelTextColor |
Color? |
null |
Custom text color for the cancel button. |
isDestructive |
bool |
false |
Uses destructive styling for warning confirmation actions. |
AppDialog now uses one clearer glass surface, a restrained blur, a
fade/scale entrance animation, and a scrollable height constrained by the
keyboard insets. Input dialogs move above the keyboard instead of being
covered by it. The default cancel action is outlined while the primary action
remains filled.
Code Usage Example:
class DialogSampleWidget extends StatelessWidget with Dialogs {
@override
Widget build(BuildContext context) {
return FrostedButton.primary(
label: 'Open Input Dialog',
onPressed: () async {
final result = await showAppInputDialog(
context: context,
title: 'Enter Name',
description: 'Please enter your full name below.',
hintText: 'John Doe',
validator: (val) => val == null || val.isEmpty ? 'Required' : null,
);
},
);
}
}
7. ⏳ Loading Indicator (AppLoadingIndicator)
A generic glassmorphic loading indicator built on a Lottie animation (assets/lottie/loading.json), acting as a drop-in replacement for standard CircularProgressIndicator.
Available Methods in Dialogs mixin:
showAppLoadingDialog: Shows a glassmorphic non-dismissible loading dialog featuring theAppLoadingIndicatorand an optional message.
Code Usage Example:
class LoadingSampleWidget extends StatelessWidget with Dialogs {
@override
Widget build(BuildContext context) {
return Column(
children: [
// Raw indicator
const AppLoadingIndicator(size: 40),
// Dialog wrapper
ElevatedButton(
onPressed: () => showAppLoadingDialog(
context: context,
message: 'Loading...',
),
child: const Text('Show Loading Dialog'),
),
],
);
}
}
7. 📋 Glassmorphic List Tiles (FrostedListSection & FrostedListTile)
A glassmorphic list section that groups multiple list tiles together. It automatically handles rounded corners and dividers between tiles, mimicking native iOS settings menus but with a modern glass look.
API & Key Parameters:
| Parameter | Type | Default | Description |
|---|---|---|---|
header |
Widget? |
null |
Header widget displayed above the section. |
children |
List<Widget> |
Required | List of FrostedListTiles. |
margin |
EdgeInsetsGeometry |
EdgeInsets.symmetric(horizontal: 16.0, vertical: 8.0) |
Margin around the section. |
separatorColor |
Color? |
dividerColor |
Color of the divider line between tiles. |
Code Usage Example:
class SettingsSampleWidget extends StatelessWidget {
@override
Widget build(BuildContext context) {
return FrostedListSection(
header: const Text('Preferences'),
children: [
FrostedListTile(
title: const Text('Notifications'),
trailing: const Icon(Icons.chevron_right),
onTap: () {},
),
FrostedListTile(
title: const Text('Privacy'),
trailing: const Icon(Icons.chevron_right),
onTap: () {},
),
],
);
}
}
8. 🖼️ Screen Scaffold Layout (BaseWidget, FrostedAppBar & FrostedNavigationButtomBar)
Screen scaffold wrapper ensuring consistent layout padding, safe areas, and a floating glass app bar (FrostedAppBar) as well as an optional floating glass bottom navigation bar (FrostedNavigationButtomBar).
API & Key Parameters (BaseWidget):
| Parameter | Type | Default | Description |
|---|---|---|---|
child |
Widget |
Required | Body content widget. |
title |
String? |
null |
Title displayed inside the glass FrostedAppBar. |
actions |
List<Widget>? |
null |
End-aligned action icons in FrostedAppBar. |
isHideAppbar |
bool |
false |
Hides the top app bar when true. |
hideAppBarOnScroll |
bool |
false |
Hides the default floating app bar while scrolling down and reveals it after at least 1 logical pixel of upward scrolling. |
appBarScrollBehavior |
AppBarScrollBehavior |
none |
Selects none, hideAll, or collapseTitle behavior. |
hideAfter / showAfter |
double |
16 / 8 |
Hysteresis distances in logical pixels used to prevent flickering. |
titleWidget |
Widget? |
null |
Custom title content for the default app bar. |
showStatusBarGradient |
bool |
true |
Adds a theme-aware status-bar gradient: dark scaffold tint in dark mode and a subtle black-to-transparent tint in light mode. |
bottomNavigationBar |
Widget? |
null |
Optional bottom bar component. |
API & Key Parameters (FrostedNavigationButtomBar):
| Parameter | Type | Default | Description |
|---|---|---|---|
controller |
FrostedNavbarController |
Required | Controller managing the active tab index. |
items |
List<FrostedNavbarItem> |
Required | List of tab items to display (data class). |
action |
Widget? |
null |
Optional action widget (e.g. FAB) displayed at the end. |
onTabChanged |
ValueChanged<int>? |
null |
Global callback executed when any tab is tapped. |
Code Usage Example:
class MyScreen extends StatefulWidget {
@override
State<MyScreen> createState() => _MyScreenState();
}
class _MyScreenState extends State<MyScreen> {
final FrostedNavbarController _navController = FrostedNavbarController();
@override
void dispose() {
_navController.dispose();
super.dispose();
}
@override
Widget build(BuildContext context) {
return BaseWidget(
title: 'Dashboard',
actions: [
IconButton(icon: const Icon(Icons.settings_outlined), onPressed: () {}),
],
bottomNavigationBar: FrostedNavigationButtomBar(
controller: _navController,
onTabChanged: (index) {
print('Tab changed to $index');
},
items: [
FrostedNavbarItem(icon: Icons.home, title: 'Home'),
FrostedNavbarItem(icon: Icons.search, title: 'Search', badgeCount: 3),
],
action: appFab(context: context, icon: Icons.add, onPressed: () {}),
),
child: const Center(child: Text('Screen Content')),
);
}
}
Scroll-to-hide app bar
Set appBarScrollBehavior: AppBarScrollBehavior.hideAll when a screen should
reclaim the top edge while the user scrolls down. The default floating
FrostedAppBar hides after hideAfter logical pixels and returns after
showAfter logical pixels. The different thresholds prevent flickering when
the user's finger changes direction. It also remains visible when the scroll
position reaches the top. Reaching or bouncing at the bottom does not count as
an upward reveal; the bar returns only after content actually moves upward away
from the bottom edge.
The option is disabled by default and applies only to the default floating
app bar. A custom appbar passed to BaseWidget continues to use the normal
Scaffold.appBar behavior. The implementation changes state only when the
visibility direction changes, keeps the scrollable child outside the animated
app-bar subtree, and pauses app-bar animations while hidden. This avoids
rebuilding the page content and limits extra work while the glass blur is
moving.
Use AppBarScrollBehavior.collapseTitle to keep the back button and actions
available while fading out only the title. This is useful on detail pages
where navigation actions should remain reachable. The legacy
hideAppBarOnScroll: true option is still supported and maps to hideAll.
BaseWidget(
title: 'Messages',
appBarScrollBehavior: AppBarScrollBehavior.hideAll,
child: ListView.builder(
itemCount: 50,
itemBuilder: (context, index) => ListTile(title: Text('Message $index')),
),
)
7. 🚦 Glassmorphic Stepper (FrostedStepper & Steppers)
A multi-step progress indicator designed with the liquid glass aesthetic. Supports both horizontal and vertical orientations.
Available Mixin Methods:
appStepper: Returns aFrostedStepperinstance.
API & Key Parameters:
| Parameter | Type | Default | Description |
|---|---|---|---|
controller |
FrostedStepperController |
Required | Manages the current step and navigation. |
direction |
FrostedStepperDirection |
horizontal |
Layout direction (horizontal or vertical). |
activeColor |
Color? |
primary |
Color for active steps and completed lines. |
inactiveColor |
Color? |
outlineVariant |
Color for inactive steps and remaining lines. |
textColor |
Color? |
onPrimary |
Color for the step number text. |
lineSize |
double |
2 |
Thickness of the connecting line. |
stepSize |
double |
32 |
Diameter of the step circle. |
Code Usage Example:
class StepperSampleWidget extends StatefulWidget {
@override
State<StepperSampleWidget> createState() => _StepperSampleWidgetState();
}
class _StepperSampleWidgetState extends State<StepperSampleWidget> with Steppers {
late FrostedStepperController _controller;
@override
void initState() {
super.initState();
_controller = FrostedStepperController(
steps: 3,
stepsList: ['Cart', 'Address', 'Payment'],
);
}
@override
void dispose() {
_controller.dispose();
super.dispose();
}
@override
Widget build(BuildContext context) {
return appStepper(
controller: _controller,
direction: FrostedStepperDirection.horizontal,
);
}
}
🔐 Generic Authentication Catalog (features/auth)
The authentication module provides ready-to-use pure UI screens and forms for sign-in, registration, password recovery, and email verification:
AuthScreen: Complete unified page featuring sliding tabs between Sign In and Register.LoginFormWidget: Standalone sign-in form usingemailFieldandpasswordField.RegisterFormWidget: Account creation form with name, email, password, and confirm password.ForgotPasswordFormWidget: Reset email request form.ResetPasswordFormWidget: Token verification and new password entry form.VerifyEmailFormWidget: Email token confirmation form.AuthController: Pure UI state manager for view modes, loading states, and user feedback.
Feature Flags & Custom Overrides
Both AuthScreen and AuthView accept the following optional boolean parameters (all default to true) to allow you to disable specific authentication flows, making the UI highly reusable across different applications:
- showRegisterButton
- showForgotPasswordButton
- showResetTokenButton
- showVerifyTokenButton
Additionally, you can completely override the default buttons with your own custom Widgets using:
- customLoginButton
- customRegisterButton
- customForgotPasswordButton
- customResetTokenButton
- customVerifyTokenButton
// Example embedding AuthScreen with disabled features and a custom login button:
AuthScreen(
showRegisterButton: false, // Disables registration
showForgotPasswordButton: false, // Disables forgot password
showResetTokenButton: false,
showVerifyTokenButton: false,
customLoginButton: ElevatedButton(
onPressed: () {},
child: Text('My Custom Login Button'),
),
onLoginSuccess: () {
Navigator.of(context).pushReplacementNamed('/home');
},
);
🔑 Tour & Onboarding Support (Widget Keys)
To fully support in-app tutorials, interactive tours, and automated testing, every widget and mixin generator method in frosted_ui_kit now accepts an optional Key? key parameter.
When building an onboarding flow (using packages like showcaseview or tutorial_coach_mark), you can assign a GlobalKey to any internal UI component seamlessly.
Example Usage:
final GlobalKey myButtonKey = GlobalKey();
appButton(
key: myButtonKey, // Pass the key directly to the mixin generator
context: context,
title: 'Start Tour',
onPressed: () => _startTour(),
);
This applies to all components including:
- Mixin generators (appButton, textField, showAppBottomSheet, showAppWarningDialog, blurredCard, appSlidingTabs, appStepper, etc.)
- Direct widget instantiations (AppButton, AppTextField, BaseWidget, etc.)
- Bottom Sheets and Dialogs via their mixin launchers.
Rendering modes and scroll stability
All glass components follow the same explicit Full, Balanced and Lite policy, including Android cards, water-drop controls, app bars, navigation bars and modal surfaces. See Shared glass rendering for precedence, route inheritance, tint limitations and scroll-driven header behavior.
🚀 Quick Start
This guide takes a new Flutter project from installation to its first glass surface without requiring knowledge of the repository's internal structure.
1. Install the package
Add the package from pub.dev to pubspec.yaml:
dependencies:
frosted_ui_kit: ^1.2.0
Then run flutter pub get.
For local package development only, use a path relative to your own app:
dependencies:
frosted_ui_kit:
path: ../frosted_ui_kit
2. Copy-paste example
Place this file in lib/main.dart. It is self-contained and does not import
anything from the package's internal example application:
import 'package:material_ui/material_ui.dart';
import 'package:frosted_ui_kit/frosted_ui_kit.dart';
void main() => runApp(const QuickStartApp());
class QuickStartApp extends StatelessWidget {
const QuickStartApp({super.key});
@override
Widget build(BuildContext context) {
return FrostedPerformance.fromData(
data: FrostedPerformance.balanced,
child: MaterialApp(
debugShowCheckedModeBanner: false,
theme: ThemeData(
brightness: Brightness.light,
useMaterial3: true,
extensions: const [FrostedThemeData.light],
),
darkTheme: ThemeData(
brightness: Brightness.dark,
useMaterial3: true,
extensions: const [FrostedThemeData.dark],
),
themeMode: ThemeMode.system,
home: const QuickStartPage(),
),
);
}
}
class QuickStartPage extends StatelessWidget {
const QuickStartPage({super.key});
@override
Widget build(BuildContext context) {
return Scaffold(
body: Center(
child: Padding(
padding: const EdgeInsets.all(24),
child: Column(
mainAxisSize: MainAxisSize.min,
children: [
const Text('Welcome', style: TextStyle(fontSize: 28)),
const SizedBox(height: 20),
FrostedButton.primary(
label: 'Open sheet',
onPressed: () => showModalBottomSheet<void>(
context: context,
backgroundColor: Colors.transparent,
isScrollControlled: true,
builder: (_) => const AppBottomSheet(
title: 'Quick action',
child: Text('Your glass surface is ready.'),
),
),
),
const SizedBox(height: 12),
FrostedButton.secondary(
label: 'Show dialog',
onPressed: () => showDialog<void>(
context: context,
builder: (_) => const AppDialog(
child: Text('Dialogs adapt to small screens and keyboards.'),
),
),
),
],
),
),
),
);
}
}
For standardized results, use the Dialogs and BottomSheets mixins and
helpers such as showAppWarningDialog and showAppInputDialog.
3. Configure the theme
Add FrostedThemeData to ThemeData.extensions. Local widget properties take
precedence over theme tokens, followed by the package defaults:
ThemeData(
extensions: const [
FrostedThemeData(
dialogRadius: 28,
buttonRadius: 18,
dialogBlur: 10,
spacing: 14,
),
],
)
Use FrostedPerformance.full for high-end devices, balanced as a practical
general default, and lite for low-end devices or reduced-transparency modes:
FrostedPerformance.fromData(
data: FrostedPerformance.lite,
child: MaterialApp(home: const QuickStartPage()),
)
lite disables BackdropFilter while preserving layout, interaction, and the
core translucent surface treatment.
4. Configure localization
Add flutter_localizations to the application and provide delegates and
supported locales:
MaterialApp(
localizationsDelegates: const [
AppLocalizations.delegate,
GlobalMaterialLocalizations.delegate,
GlobalWidgetsLocalizations.delegate,
GlobalCupertinoLocalizations.delegate,
],
supportedLocales: AppLocalizations.supportedLocales,
)
The package provides defaults for common actions such as confirm, cancel,
and ok. Applications can pass their own localized strings to dialog APIs;
the package does not force a single language.
5. Choose the right component
| Need | Recommended component | Typical use |
|---|---|---|
| Regular action | FrostedButton.primary |
Save, continue, send |
| Safe or cancel action | FrostedButton.secondary |
Back, cancel, close |
| Dangerous action | FrostedButton.destructive |
Delete, disable, remove |
| Icon-only action | FrostedIconButton or CircleButton |
Settings, back, add |
| Async operation | FrostedAsyncButton |
Save or upload with feedback |
| Text input | AppTextField or showAppInputDialog |
Forms and search |
| Confirmation | showAppWarningDialog |
Decisions requiring confirmation |
| Error message | showAppErrorDialog |
Failed operations and warnings |
| Bottom content | showAppBottomSheet |
Options and details |
| Full screen layout | BaseWidget |
Floating app bar and scroll behavior |
6. Migration from older APIs
No migration is required. Existing names and mixins remain supported,
including BluredCard and the legacy button APIs. For new code:
- Prefer
BlurredCard;BluredCardremains a compatibility alias. - Prefer
FrostedButtonfor everyday actions andAppButtonfor advanced customization. - Pass
role: FrostedActionRole.destructiveinstead of inferring risk from color. - Use
FrostedPerformanceinstead of disablingBackdropFilterper component. - Use
showAppInputDialogorAppDialog(actions: ...)for keyboard-aware layouts.
For advanced details, see FrostedThemeData, shared glass surfaces, and adaptive dialogs and bottom sheets.
🎨 Central Theme Tokens (FrostedThemeData)
Import frosted_ui_kit.dart and install FrostedThemeData in
ThemeData.extensions. Light/dark presets inherit colors from the matching
Material ColorScheme instead of creating separate color schemes per widget.
final theme = ThemeData(
extensions: const [FrostedThemeData(
surfaceColor: Color(0xFFE6F0F4),
contentColor: Color(0xFF172B36),
borderColor: Color(0x55778899),
buttonRadius: 20,
dialogRadius: 28,
glassBlur: 4,
dialogBlur: 10,
appBarBlur: 4,
spacing: 12,
motionDuration: Duration(milliseconds: 180),
)],
);
Resolution: explicit local property, then theme token, then existing default. Generic cards inherit surface/border/radius/blur. Regular buttons inherit radius and foreground; water-drop surfaces inherit tint/blur. AppBar inherits blur, and Dialog inherits surface/opacity/radius/blur/spacing/entrance duration. Tabs and input fields inherit buttonRadius and their own blur tokens. Bottom sheets inherit surface tint, sheetBlur and dialogRadius + 4 for the top corners. Navigation inherits borderColor, navigationBlur and twice buttonRadius. Tabs use motionDuration for text and 1.25 times that duration for sliding feedback. A filled primary button still uses its ColorScheme primary. Local style overrides remain available; fixed functional measurements such as drag handles and icon sizes intentionally remain separate from design tokens.
Action roles can be customized independently from button appearance with
primaryActionColor/onPrimaryActionColor,
secondaryActionColor/onSecondaryActionColor, and
destructiveActionColor/onDestructiveActionColor. Null role colors inherit
the matching primary, secondary, or error pair from Material ColorScheme.
The resolution order is local widget color, role token, then ColorScheme.
Disabled colors derive from onSurface; interaction overlays derive from the
resolved role accent.
Component blur defaults preserve existing appearances: inputBlur 10, tabsBlur 10, sheetBlur 15, navigationBlur 20. For a lighter recipe:
const FrostedThemeData(
inputBlur: 4,
tabsBlur: 4,
sheetBlur: 8,
navigationBlur: 6,
)
Instances are immutable and const defaults are reused. Lookup uses the normal
Theme inherited dependency; no additional controller, timer or listener is
created. lerp supports theme transitions with endpoint fast paths. copyWith
retains nullable colors when omitted; construct a fresh instance to clear them.
Blur performance settings remain independent of design tokens. No device FPS
or GPU improvement is claimed without profiling.
Compatibility: constructor calls remain supported. BlurredCard.sigmaX/Y,
FrostedAppBar.sigmaX/Y, and AppDialog.surfaceOpacity/blurSigma are now
nullable overrides so an omitted value can inherit the theme. Code directly
reading these public fields must handle null. Existing defaults and geometry
goldens pass when no custom extension is installed.
The sigmaX/Y override fields and helper arguments on inputs, tabs and sheets are nullable too, to distinguish omitted values from explicit overrides. Their effective defaults are unchanged. Code reading these fields should resolve them against the matching token.
Verification: copyWith, lerp endpoints/interpolation, fallback, local surface override and button radius; complete widget/golden suite. Extend token coverage tests alongside further component migrations.
🔬 Shared Glass Rendering Architecture
All kit backdrop filters are built by the internal GlassBackdrop primitive.
Cards and water-drop buttons retain their own tint, border, shadow and content
layout; the primitive owns bounded clipping and blur only. No extra controller,
timer, raster cache or unconditional RepaintBoundary is introduced.
FrostedPerformance is exported from the main library. Global blurEnabled and
blurScale apply to all surfaces. Lite and zero scale create no backdrop filter.
All surfaces use the Android alpha fallback only when no explicit performance
scope exists. Full and Balanced explicitly enable blur on Android and iOS.
Cards retain local disableBlur; explicit colors are retained. Default card fallback uses fallbackOpacity in lite.
A private inherited marker prevents a nested kit surface from adding a second blur when an ancestor already filters its backdrop. This intentionally changes stacked glass: an input inside a glass dialog uses the dialog's blur, keeping its own tint and border. Nested stronger blur is not independently applied. Independent siblings keep separate filters; overlapping siblings are not given a shared BackdropKey, which could produce incorrect compositing.
Animated child content stays in its original layer order. Moving it or adding raster boundaries requires profile measurements, tracked in P1. Dialog entrance and button press scaling respect reduced-motion settings. Full animation policy for other components is outside this rendering refactor.
Tests verify ancestor filter reuse, independent siblings, lite and zero scale, balanced scaling once, and existing light/dark geometry goldens. These establish render-tree behavior and visual regression protection, not a measured FPS gain.
Rendering mode precedence
- Global disabled blur or zero scale disables every kit backdrop.
- A card with
disableBlur: trueremains unblurred. - An explicit Full or Balanced scope enables all glass surfaces on every platform.
- Without a scope, Android uses alpha transparency; other platforms use blur.
A card may opt in with
disableBlur: false.
The same policy covers cards, app-bar titles, navigation bars, glass and water-drop buttons, FABs, glass loading buttons, text fields, tabs, list sections, bottom sheets and dialogs. Solid/outlined/text button styles, non-glass inputs, badges, separators and stepper connectors remain intentional non-backdrop decorations. Alpha blending is still present in Lite: it is not an opaque or reduced-transparency accessibility mode.
FrostedPerformance is an InheritedTheme, so Flutter captures a local scope
when opening a dialog or bottom sheet. Captured local settings are a snapshot
at route creation. Place a live application-wide scope above MaterialApp
when open routes must react to rendering-mode changes.
Explicit opaque tints still hide the visual blur, and a uniform background has no details to blur. Rendering mode changes the filter, not caller-supplied colors.
Scroll-driven app bars
BaseWidget accumulates actual primary vertical scroll deltas against
hideAfter and showAfter. Direction-only notifications do not toggle the bar.
At the leading edge (including top bounce), the bar stays visible and movement
counters reset. Out-of-range overscroll, horizontal and nested viewport
notifications do not toggle it. Disabling the scroll behavior restores visibility;
rebuilding a screen with collapseTitle does not reset its hidden state.
Regression tests cover all glass component families in Full, Balanced and Lite on Android and iOS, modal route capture, top bounce and distance thresholds. They do not replace on-device visual and frame-time profiling.
Adaptive Dialogs and Bottom Sheets
Dialogs and bottom sheets share FrostedAdaptiveSurfaceLayout, which divides a
modal surface into optional header, scrollable body, and optional actions.
This keeps behavior consistent across compact phones, tablets, large text,
RTL, and keyboard-visible layouts.
Layout behavior
On a regular viewport the header and actions remain visible while only the body scrolls. When available height is too small, all three regions move into one scroll view. The threshold scales with accessibility text size so a large header or stacked actions cannot overflow.
FrostedAdaptiveActions displays secondary and primary actions in one row when
space allows. Below 360 logical pixels, or at a text scale of 1.3 and above,
the actions stack vertically with full-width touch targets. Secondary remains
before primary, keeping the safe action ahead of a destructive action.
Dialog usage
AppDialog(
header: Text(appStrings.deleteTitle),
actions: FrostedAdaptiveActions(
secondary: FrostedButton.secondary(
label: appStrings.cancel,
onPressed: cancel,
),
primary: FrostedButton.destructive(
label: appStrings.delete,
onPressed: confirmDelete,
),
),
child: Text(appStrings.deleteDescription),
)
showAppWarningDialog(isDestructive: true) assigns the destructive role to
the confirmation action. Default Confirm, Cancel, Submit, and OK labels follow
FrostedAppLocalizations when its delegate is installed. Explicit strings
continue to take precedence.
Input dialogs retain one validation path for keyboard Done and the confirmation button. Dialog constraints continue to account for keyboard insets without adding them twice.
Bottom-sheet usage
showAppBottomSheet(
context: context,
title: appStrings.settings,
actions: FrostedButton.primary(
label: appStrings.save,
onPressed: save,
),
child: const SettingsForm(),
)
AppBottomSheet animates the complete surface above viewInsets.bottom
instead of inserting a large empty spacer inside its content. Its height is
clamped to the usable viewport through maxHeightFactor, which defaults to
0.92. header can replace the title row; showCloseButton, showDragHandle,
and closeTooltip customize the default chrome.
Performance on lower-end devices
Each modal owns one BlurredCard surface. Nested kit controls detect the glass
ancestor and do not create another backdrop blur. Bottom sheets use
Clip.hardEdge by default, avoiding anti-aliased save layers for routine
clipping.
All surfaces honor FrostedPerformance. In lite mode no BackdropFilter is
created; the opaque fallback preserves contrast and geometry. Balanced mode
scales sigma once. Keyboard padding uses the shared theme duration and becomes
immediate when reduced motion is active. No FPS claim is made without
profile-mode device measurements.
Compatibility
Existing child, title, sizing, glass, drag, and dismissal parameters remain
supported. New header and actions parameters are additive. Existing custom
dialog children continue to render, so applications can migrate incrementally.
Verification
Widget tests cover destructive roles, 320px width with 2x text, keyboard insets, a long bottom-sheet body, localized default actions, and blur counts in full and lite modes. Existing dialog validation, rotation, RTL, and keyboard tests remain part of the full suite.
Brand Assets
Frosted UI Kit uses a glass droplet mark with a lavender-to-cyan highlight on a deep indigo field. The mark represents the library's two core ideas: translucent surfaces and fluid interaction.
Logo
The source logo is available at:
assets/brand/frosted_ui_kit_logo.png
The same source is copied into the example app so native platform icons and the Flutter asset catalog remain visually aligned.
Usage guidance
- Use the full mark on dark or neutral backgrounds.
- Keep clear space around the mark equal to at least one quarter of its width.
- Do not recolor, stretch, crop, or add text inside the mark.
- For small UI sizes, use the icon without a wordmark; the mark is designed to remain recognizable at compact sizes.
Example application icon
The example app uses the same mark for Android, iOS, macOS, and web icons. Platform-specific sizes are generated from the source image to avoid separate variants drifting apart over time.
API Stability and Deprecation
Public entry point
Application code should import package:frosted_ui_kit/frosted_ui_kit.dart.
The package entry point exports the supported widgets, theme data, performance
configuration, localization types, and generic authentication types. Internal
src/ imports are not part of the compatibility contract.
The public entry point is intentionally grouped into these API areas:
| Area | Public types |
|---|---|
| Surfaces and layout | BlurredCard, GlassBackdrop, BaseWidget, FrostedAdaptiveSurfaceLayout |
| Navigation | FrostedAppBar, FrostedNavigationBottomBar, FrostedNavbarController |
| Buttons and loading | AppButton, CircleButton, FrostedButton, FrostedAsyncButton, FrostLoadingButton |
| Inputs and modals | AppTextField, AppDialog, AppBottomSheet |
| Design system | FrostedThemeData, FrostedPerformance, FrostedPerformanceData |
| Supporting components | tabs, steppers, list tiles, loading indicators, localization, and generic auth types |
The auth data and domain exports remain public for 1.x compatibility. New applications should depend on the domain contracts and presentation widgets; the data implementations are exported only to support existing integrations. The authentication review and lifecycle ownership rules are documented in Authentication API Review.
Authentication-only consumers may instead import the optional facade:
import 'package:frosted_ui_kit/auth.dart';
Compatibility policy
Existing 1.x APIs are retained when a spelling or naming correction is made. Deprecated APIs remain available and forward to the canonical implementation.
| Deprecated API | Canonical API |
|---|---|
CricleButton |
CircleButton |
BluredCard |
BlurredCard |
Cards.bluredCard |
Cards.blurredCard |
FrostedNavigationButtomBar |
FrostedNavigationBottomBar |
No deprecated API is removed as part of this compatibility pass.
Migration guidance
Replace deprecated names when touching existing code. Projects that need a gradual migration can keep the old names temporarily; behavior and layout are unchanged because the aliases delegate to the same implementation.
Breaking changes require a changelog entry, migration notes, and a major version.
FrostedAsyncButton
FrostedAsyncButton is the beginner-friendly API for a button that starts a
Future. It owns loading, success, error, repeat-tap prevention, feedback
timing, and mounted checks. No controller or setState is required.
Basic usage
FrostedAsyncButton(
title: appStrings.save,
icon: Icons.save_outlined,
onPressed: () async => repository.save(),
onSuccess: showSavedMessage,
onError: (error, stackTrace) => logger.record(error, stackTrace),
)
The application supplies localized title, loadingLabel, successLabel,
and errorLabel values when the defaults do not match its language.
State lifecycle
- The idle button accepts one activation.
- Its state changes to loading synchronously, before awaiting the callback. A second pointer, keyboard, or semantics activation is rejected.
- A completed Future shows success; a thrown error shows error and is passed
to
onErrorwith its stack trace. - The button returns to idle after
feedbackDuration, which defaults to 1.2 seconds. Set it tonullto retain the terminal state while the widget remains mounted.
The widget never opens a Dialog, SnackBar, or retry UI automatically. Those decisions remain in application code.
Lifecycle and late results
Disposing the widget cancels its feedback timer and invalidates the active
operation generation. The application Future itself is not canceled because a
generic Dart Future has no cancellation contract. When that Future completes
after unmount, the result is consumed without setState, controller updates,
or success/error callbacks.
For cancellable network work, cancellation remains the responsibility of the repository or request client. Pass its cancellation signal through the application callback.
Appearance and role
style controls appearance and role controls semantic colors, matching
AppButton. A destructive asynchronous action can therefore use a glass
surface without losing its error color family:
FrostedAsyncButton(
title: appStrings.deleteAccount,
role: FrostedActionRole.destructive,
style: AppButtonStyle.glass,
onPressed: accountRepository.delete,
)
Choosing the correct API
| Need | API |
|---|---|
| Run one Future and show automatic feedback | FrostedAsyncButton |
| Application code drives every state manually | FrostLoadingButton |
| Normal synchronous action | FrostedButton or AppButton |
FrostLoadingButtonController remains supported and is not deprecated.
Verification
Widget tests cover synchronous repeat blocking, success and automatic reset,
captured errors and retry, disabled semantics, and completion after unmount.
The full package test suite and flutter analyze must pass before release.
Authentication API Review
Current contract
The authentication module is generic at its domain boundary:
UserEntitycarries app-specific attributes throughcustomData.AuthRepositoryis the application-facing contract.AuthRemoteDataSourceis an injectable backend adapter.AuthControllerowns view state and can be supplied by the host app.AuthScreenandAuthViewexpose flow flags and button overrides.
The data models and mock data source remain exported for 1.x compatibility and
for package examples. Applications with a real backend should provide their
own AuthRemoteDataSource and AuthRepository implementation.
Lifecycle correction
AuthScreen no longer creates a throwaway AuthController inside build.
When no controller is supplied, AuthView creates exactly one local controller
and disposes it with the view. When a controller is supplied, ownership stays
with the caller.
This prevents duplicate listeners, unnecessary allocations, and state updates being sent to a controller different from the one rendering the forms.
Remaining follow-up
The controller currently contains default English feedback messages for the legacy standalone auth flow. A future major API can expose message builders or localized callbacks without changing the repository contract. Existing strings are retained for compatibility in the current release.
Frosted UI Kit Performance Policy
FrostedPerformance is the single performance policy for glass surfaces in
frosted_ui_kit. It lets an application choose the rendering cost once at the
root of a widget tree instead of configuring every component independently.
Presets
FrostedPerformance.fromData(
data: FrostedPerformance.balanced,
child: MaterialApp(home: const HomePage()),
)
| Preset | Backdrop blur | Blur scale | Recommended use |
|---|---|---|---|
full |
Enabled | 1.0 |
Flagship devices and desktop |
balanced |
Enabled | 0.5 |
General mobile default |
lite |
Disabled | 1.0 |
Low-end devices and reduced transparency |
lite removes BackdropFilter entirely. It keeps the same layout, surface
geometry, interaction, borders, and translucent fallback fill, so changing
the policy does not cause a layout shift.
Component contract
Every shared glass surface must:
- Read
FrostedPerformance.of(context). - Skip
BackdropFilterwhenblurEnabledis false. - Multiply requested sigma values by
blurScaleexactly once. - Preserve dimensions and decoration in all presets.
- Avoid nested filters through the shared
GlassBackdropscope. - Keep clipping bounded to the surface shape.
Without a performance scope, all glass surfaces default to the lightweight alpha
fallback on Android. An explicit Full or Balanced scope enables blur on Android
as well as iOS. BlurredCard.disableBlur: true opts an individual card out;
disableBlur: false opts it in when no scope exists. Global disabled blur and
zero scale always win. See Shared glass rendering for modal
route capture and component coverage.
Choosing a mode at runtime
Expose the policy as an application setting or derive it from a device-tier decision. Do not toggle it on every frame. A single inherited update rebuilds only the surfaces that depend on the policy:
class AppRoot extends StatelessWidget {
const AppRoot({super.key, required this.mode});
final FrostedPerformanceData mode;
@override
Widget build(BuildContext context) {
return FrostedPerformance.fromData(
data: mode,
child: const MaterialApp(home: HomePage()),
);
}
}
Use lite when the platform requests reduced transparency, when sustained
raster work is too high, or on low-end hardware. Use balanced before choosing
full as the default for a broad mobile audience.
Measurement protocol
Performance claims must be made from profile builds, not debug mode:
flutter run --profile -d <device-id>
flutter drive --profile --no-dds -d <device-id> \
--driver=test_driver/integration_test.dart \
--target=integration_test/performance_test.dart
The repository includes a repeatable example scenario at
example/integration_test/performance_test.dart. Run it from the example
directory:
flutter drive --profile --no-dds -d <device-id> \
--driver=test_driver/integration_test.dart \
--target=integration_test/performance_test.dart
The test reports a catalog_scroll timeline suitable for comparing the same
build with full, balanced, and lite. The app starts in balanced; change
the Rendering Mode in Catalog settings and rerun the same scenario for the
other modes.
Record the device model, OS, Flutter version, preset, screen, scroll scenario,
and warm-up duration. Capture build time, raster time, frame timing, and jank.
Compare the same scenario in full, balanced, android, and lite. This repository
does not claim a fixed FPS or percentage improvement without those measurements.
For Android scrolling-heavy screens, the explicit android preset removes
backdrop readback while preserving surface geometry, opacity, borders, and
semantics:
FrostedPerformance.fromData(
data: FrostedPerformance.android,
child: MaterialApp(home: MyHomePage()),
)
Use balanced when reduced blur is acceptable, and use full only when the
device and screen can sustain the additional raster work.
Android baseline (2026-11-08)
The first physical baseline was captured with the repeatable catalog_scroll
scenario in balanced mode:
| Field | Value |
|---|---|
| Device | Xiaomi 24069PC21G |
| Android | 16 |
| Display | 1220 x 2712, configured for 120 Hz |
| Flutter | 3.47.9 stable |
| Build | Profile |
| Scenario | 8 down/up drag cycles, 250 ms between gestures, 2 s warm-up |
| Frames captured | 32 |
| Average build time | 0.505 ms |
| 90th / 99th build time | 1.058 / 1.439 ms |
| Worst build time | 1.439 ms |
| Average rasterizer time | 11.722 ms |
| 90th / 99th rasterizer time | 19.877 / 21.297 ms |
| Worst rasterizer time | 21.297 ms |
| Missed build budget | 0 |
| Missed raster budget | 11 of 32 frames |
At 120 Hz the frame budget is approximately 8.33 ms. The measured raster
average is therefore above the 120 Hz budget, while build work remains well
below it. The report does not emit a display FPS value; 1000 / 11.722 is an
approximate raster-work capacity of 85.3 fps, not measured on-screen FPS and
must not be presented as one. The raw report is generated at
example/build/integration_response_data.json for future comparisons.
Android preset comparison
The same scenario was rerun with FrostedPerformance.android on the same
device and build configuration:
| Metric | Balanced | Android preset | Change |
|---|---|---|---|
| Average build time | 0.505 ms | 0.561 ms | +0.056 ms |
| Average rasterizer time | 11.722 ms | 5.913 ms | -49.6% |
| 90th percentile rasterizer | 19.877 ms | 13.466 ms | -32.2% |
| Worst rasterizer time | 21.297 ms | 14.120 ms | -33.7% |
| Missed raster budgets | 11 / 32 | 0 / 32 | eliminated |
This is a device-specific baseline, not a universal FPS guarantee. The
Android preset is the recommended choice for scrolling-heavy Android screens;
the raw report at example/build/integration_response_data.json contains the
latest Android-preset run.
iOS baseline (2026-11-09)
The same catalog_scroll scenario was captured on the connected physical
device AbdulRasol's iPhone running iOS 27.0.1 in Profile mode with the
default balanced preset:
| Metric | Value |
|---|---|
| Frames captured | 32 |
| Average build time | 0.525 ms |
| 90th / 99th build time | 0.761 / 0.858 ms |
| Worst build time | 0.858 ms |
| Average rasterizer time | 10.425 ms |
| 90th / 99th rasterizer time | 13.459 ms |
| Worst rasterizer time | 19.910 ms |
| Missed build budgets | 0 |
| Missed raster budgets | 1 of 32 |
The iOS report does not expose a reliable display FPS value through this
runner, so no fixed FPS claim is made. The raw report is generated at
example/build/integration_response_data.json after each run and should be
archived with the device and preset details.
Current verification
Widget tests verify that lite creates no BackdropFilter, balanced scales
sigma once, nested glass surfaces do not add filters, and independent surfaces
remain independently bounded. The Android baseline above is intentionally
kept separate from unit tests. An iOS profile run is still required before P1
can be marked complete.
Migration Guide
This guide describes the safe migration path for existing frosted_ui_kit
applications. The 1.x compatibility policy keeps deprecated APIs available;
migrations can therefore be applied incrementally.
Import boundary
Use the package entry point for application code:
import 'package:frosted_ui_kit/frosted_ui_kit.dart';
Do not import lib/src/... paths directly. They are implementation details and
may change without preserving private structure.
Naming corrections
Replace legacy spellings when touching a file:
| Before | After |
|---|---|
CricleButton |
CircleButton |
BluredCard |
BlurredCard |
bluredCard(...) |
blurredCard(...) |
FrostedNavigationButtomBar |
FrostedNavigationBottomBar |
The old names remain available in 1.x and have the same behavior.
Performance configuration
Wrap the application or a subtree in FrostedPerformance when you need an
explicit rendering policy:
FrostedPerformance.fromData(
data: FrostedPerformance.android,
child: MaterialApp(home: MyHomePage()),
)
Use full for maximum glass fidelity, balanced for reduced blur, android
for scrolling-heavy Android screens without backdrop readback, and lite for
the lowest raster cost. Changing the preset does not change layout or
semantics.
Buttons
Visual appearance and action meaning are independent. Keep destructive meaning explicit when changing button styles:
FrostedButton.destructive(
label: 'Delete',
onPressed: deleteItem,
)
Use FrostedAsyncButton for a Future-returning action when loading, success,
error, repeat-tap prevention, and mounted checks should be managed by the
widget. Keep FrostLoadingButtonController for manual state transitions.
Dialogs and bottom sheets
The shared adaptive surface layout now handles narrow screens, large text,
keyboard insets, scrollable content, and destructive action emphasis. Existing
dialog and bottom-sheet helpers remain source-compatible. Prefer the shared
helpers over direct showDialog or showModalBottomSheet calls when adopting
the kit's visual and accessibility behavior.
App bars and navigation
BaseWidget.hideAppBarOnScroll and appBarScrollBehavior are opt-in. Existing
screens keep the previous always-visible app bar behavior unless a scroll mode
is explicitly selected.
Release checklist
Before upgrading a production app:
- Run
flutter analyzeand the application test suite. - Check RTL, large text, keyboard, and narrow-screen modal layouts.
- Run a profile scroll test on representative Android and iOS hardware.
- Replace deprecation warnings incrementally.
- Review
CHANGELOG.mdfor visual or behavior changes in the target release.
Package Layout and Example Boundary
Package source
lib/frosted_ui_kit.dart is the supported public entry point. Reusable
components live under lib/src/shared/widgets/, design-system utilities live
under lib/src/utils/, and the generic authentication module follows the
feature boundaries under lib/src/features/auth/.
The lib/main.dart file is retained only as a legacy package-local smoke-test
harness. It is not exported and is not the recommended application entry point.
Interactive example
The example/ application is the canonical showcase. It owns the catalog
screens, integration tests, profile performance scenario, and platform runner
configuration. Package consumers should copy component usage from the example
or the quick-start guide, not import files from lib/main.dart.
Dependency boundary
The package must not depend on its example. Example-only dependencies and test
drivers stay under example/, while reusable code and public API tests stay in
the package root.
Visual Consistency
The kit uses one surface language across cards, app bars, buttons, navigation, dialogs, and sheets:
- translucent fills instead of opaque white panels;
- shared rounded geometry and border treatment;
- readable foreground contrast in light and dark themes;
- explicit performance fallbacks on Android;
- custom colors remain higher priority than defaults.
The default app-bar title uses the same translucent surface family as the
water-drop controls. On Android, where the default card fallback skips
BackdropFilter, this keeps the title from becoming a visually disconnected
opaque panel. Applications can still override it with glassColor.
FrostedListTile adds a selected icon capsule, state-aware typography, and
semantic selection metadata. AppSlidingTabs uses a bordered gradient pill
with selected semantics, while FrostedStepper uses a lightweight gradient
node and current-step emphasis instead of adding another backdrop filter.
Stepper nodes also accept an optional stepBuilder for icons, images, Lottie,
or any custom widget. The builder receives the step state and its content is
constrained to the node size.
Visual regression checks cover both theme brightnesses. When changing surface tokens, verify the catalog on Android and iOS and rerun the profile scroll scenario before changing the default appearance.
